2t Electronic Floor Forklift Platform Weighing Scale Stock Single Weigh Module Cantilever Shear Beam Load Cell Sensor

Xian Ruijia Measurement Instruments Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

2t Electronic Floor Forklift Platform Weighing Scale Stock Single Weigh Module Cantilever Shear Beam Load Cell Sensor

  • 1
  • 2
  • 3

Brand Name : RUIJIA

Model Number : RJ

Certification : CE

Place of Origin : CHINA

MOQ : 1

Price : USD25 ~35/piece

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 2000 Piece/Pieces per Month

Delivery Time : 5-8 Work days

Packaging Details : Standard export packaging

Display Type : Digital Indicator

IP Rating : IP65

Material : Alloy Steel

Range : 0.3-3t

Impedance : 350Ω

Use Voltage : 5V-15V

Contact Now

2t Electronic Floor Forklift Platform Weighing Scale Stock Single Weigh Module Cantilever Shear Beam Load Cell Sensor

Features:
· High stability
· Low structural height
· High comprehensive accuracy
· Stable anti-interference signal
· Nickel-plated high-quality alloy steel
· Widely used in weighing equipment such as electronic belt scales, packaging scales, filling scales, etc. As well as in the field of automation equipment and testing.

CAPACITY T 0-3
Rated Output mV/V 2.0±0.02
Zero Balance %F.S. ±1
Non-linearity %F.S. 0.03
Hysteresis %F.S. 0.03
Non-Repeatability %F.S. 0.02
Creep (30min) %F.S. 0.02
Temp. Effect On Output %F.S./10ºC 0.03
Temp. Effect On Zero %F.S./10ºC 0.03
Response frequency Hz 10k
Material 42CrMoA/Stainless steel
impedance Ω 350
Insulation MΩ/100V DC ≥5000
Recommended Excitation V 5-15
Operating Temp. Range ºC -20-80
Safe Overload %R.C. 150
Ultimate Overload %R.C. 200
Cable Size m Φ5*3m
Cable ultimate tension N 98
TEDS Optiona

2t Electronic Floor Forklift Platform Weighing Scale Stock Single Weigh Module Cantilever Shear Beam Load Cell Sensor

Company Information

2t Electronic Floor Forklift Platform Weighing Scale Stock Single Weigh Module Cantilever Shear Beam Load Cell Sensor

Ruijia is a technical service enterprise specializing in force measurement technology research, product R & D, production, sales and service. It is mainly engaged in micro force sensors, high-precision load cells, S-type sensors, cantilever sensors, multi-dimensional force sensors, tension sensors, transmitters R & D and production of control instruments and provide system engineering control solutions. The company has modern and spacious workshops, high-quality production and testing equipment, professional R & D team and perfect management system to provide reasonable and practical solutions for our customers. With years of understanding and understanding in the field of automation, the company has always adhered to the enterprise operation concept of "user first", built a professional team in the field of automation, and provided customers with stable quality products and pre-sales and after-sales technical services. We always adhere to the tenet of independent innovation, only good products and scientific management, and always adhere to providing perfect products and system solutions, which is highly respected in our field; Constantly change and provide customers with excellent value-added services.

Our advantages
1, Professional
17+years industrial experience,Know your needs quickly
2, Wide Product Variety
include:encoders,sensors,couplings, and other instruments widely used in CNC machinery, textile machinery, steel rolling machinery, linear guide system, hydraulic system, lifting machinery,servo motor and so on
3, High cost-performence
we can also customize replacement to the same specifications as the brand you need
4, Good service
If you have any question,Welcome to feel free to contact
